A Complete Description of PVC, PP ，PE, Steel Material Honeycomb Oblique Tube Filler

Its Advantage are :

1.Can be Applied In Any Size of new or existing clarifiers to operate 4 times of normal sedimentation tank size

2. It is possible to cut coagulant dosage by up to half while maintaining a lower influent turbidity to the treatment plant filters.
3. Less filter backwashing equates to significant operating cost savings for both water and electricity.
4. New installations using tube settlers can be designed smaller because of increased flow capability.
5.  Flow of existing water treatment plants can be increased through the addition of tube settlers.
6. Tube settlers increase allowable flow capacity by expanding settling capacity and increasing the solids removal rate in settling tanks.

7.The materials are Mainly Three Kinds, namely polypropylene (PP) and PVC and SS304/316

Key Characteristics

1.Large wet week, small hydroradius,

2.The layer flow state is good. Particle settling is not disturbed by turbulence.

3.When the length of the oblique tube is 1 meter, the payload is designed at 3-5 tons/m2. V0 is controlled in the range of 2.5-3.0 mm/s and the water quality is optimal.

4. The use of glass-steel honeycomb oblique tube at the water intake, the length of the tube at 2.0-3.0 m, can be 50-100 kg / cubic meters of high turbidity of mud and sand content safe operation treatment

5. The use of oblique tube precipitation pool, its processing power is 3-5 times that of flat-flow precipitation pool, is 2-3 times the acceleration of clarification pool and pulse clarification pool.

Straight tube is mainly used for biofiltration tanks and high-load biofiltration tanks, tower biofiltration tanks, immersion biofiltration tanks (also known as contact oxidation tanks) and microbial carriers of bio-turntables, for biochemical treatment of industrial organic wastewater and urban sewage.

6. The treatment efficiency is higher than the activated sludge method, the general hydraulic load is 100-200M3/M2. day. Organic load of 2000-5000 g/m3, thus reducing the footprint

7. Aeration strength is lower than the activated sludge method, and no sludge reflux is required, so it can reduce power consumption and simplify management.

8. Less sludge volume- reduces the post-treatment workload such as sludge dehydration.

9.The resulting sludge settlement is good, which is conducive to the removal of the latter suspension

10.A wide range of water quality can be adapted. The impact load and endurance of water quality and water mutation are strong. Maintain a stable treatment.

11. Pharmaceuticals carry out scientific operation and management, regular flushing of sewage, generally do not cause clogging

12. Reinforced straight tube can also be used as a natural or mechanical ventilation cooling tower cooling device, due to larger than the surface area, high porosity, low ventilation resistance, thermal capacity is much higher than the cement grid and wood grid structure. Also because of good heat resistance, the general plastic oblique corrugated filler use cycle is longer, honeycomb straight tube can also be used as insulation sound insulation.、

Specification of Lamella Clarifier Packing

Comment:

1.The PVC, PP thickness can be tailored design

2.The Length of the filler normally Have 900/1000/1200mm three size, for special size, need welding forming

3.The Diameter of Tube in clarifier can be as per clarifier capacity and sludge thickness to choose right one

Why Tube Settlers ?

Tube settlers offer an inexpensive method of upgrading existing water treatment plant clarifiers and sedimentation basins to improve performance.
They can also reduce the tankage/footprint required in new installations or improve the performance of existing settling basins by reducing the solids loading on downstream filters.Made of lightweight PVC,

tube settlers can be easily supported with minimal structures that often incorporate the effluent trough supports.

They are available in a variety of module sizes and tube lengths to fit any tank geometry, with custom design and engineering offered by the manufacturer.
